X Series Data Sheet
?
Table 9: Harmonics and flicker
375, 500 Watt AC-DC and DC-DC DIN-Rail Converters
Phenomenon
Harmonics
Voltage fluctuation and flicker
Standards
EN 61000-3-2:2006
EN 61000-3-3 + A2:2005
Conditions
V i = 230 V, V o nom , I o nom
V i = 230 V, V o nom , I o nom
Results
Class A, D
Complied
Immunity to Environmental Conditions
Table 10: Mechanical stress and climatic
Test method
Standard
Test conditions
Status
Cab Damp heat
steady state
IEC/EN 60068-2-78
MIL-STD-810D sect. 507.2
Temperature:
Relative humidity:
Duration:
40 ±2 °C
93 +2/-3 %
56 days
Converter
not
operating
Kb
Salt mist, cyclic
(sodium chloride
NaCl solution)
IEC/EN 60068-2-52
Concentration:
Duration:
Conditions:
5% (30 °C)
2 h per cycle
40 °C, 93% rel. humidity
Converter
not
operating
Storage duration:
3 cycles of 22 h
Eb
Bump
(half-sinusoidal)
IEC/EN 60068-2-29
MIL-STD-810D sect. 516.3
Acceleration amplitude:
Bump duration:
25 g n = 245 m/s 2
11 ms
Converter
not operating ,
6000 bumps:
Acceleration amplitude:
Bump duration:
6000 bumps:
1000 in each direction
10 g n = 98.1 m/s 2
11 ms
1000 in each direction
wall-mounted 1
Converter
not operating ,
on DIN-rail 2
Fc
Vibration
(sinusoidal)
IEC/EN 60068-2-6
MIL-STD-810D sect. 514.3
Acceleration amplitude and
frequency (1 Octave/min):
0.35 mm (10 – 60 Hz)
5 g n = 49 m/s 2 (60 – 2000 Hz)
Converter
operating,
Test duration:
Acceleration amplitude and
frequency (1 Octave/min):
Test duration:
7.5 h (2.5 h each axis)
0.25 mm (10 – 60 Hz)
2 g n = 19 m/s 2 (60 – 2000 Hz)
7.5 h (2.5 h each axis)
wall-mounted 1
Converter
operating,
on DIN-rail 2
Ea
Shock
(half-sinusoidal)
IEC/EN 60068-2-27
MIL-STD-810D sect. 516.3
Acceleration amplitude:
Bump duration:
50 g n = 490 m/s 2
11 ms
Converter
not operating ,
Number of bumps:
18 (3 in each direction)
wall-mounted 1
Fh
Random vibration
broad band
digital control and
IEC/EN 60068-2-64
Acceleration spectral density:
Frequency band:
Acceleration magnitude:
0.05 g n2 /Hz
20 – 500 Hz
4.9 g n rms
Converter
operating,
wall-mounted 1
guidance
Test duration:
3 h (1 h each axis)
Fda Random vibration
wide band
reproducibility
high
IEC/EN 60068-2-35
Acceleration spectral density:
Frequency band:
Acceleration magnitude:
Test duration:
0.01 g n2 /Hz
20 – 500 Hz
2.2 g n rms
1.5 h (0.5 h each axis)
Converter
operating,
mounted on a
DIN-rail 2
1
2
Wall-mounted with brackets UMB-W [HZZ00618]; see Accessories
Fastened on a DIN-rail with 2 additional DIN-rail fixing brackets DMB-EWG; see Accessories. This also covers wall-mounting with
brackets, because wall mounting performs better in vibration test.
Temperatures
Table 11: Temperature specifications, valid for an air pressure of 800 - 1200 hPa (800 - 1200 mbar)
Model
Standard models -6
Unit
Characteristics
Conditions
min
max
T A
T C
T S
Ambient temperature
Case temperature
Storage temperature
Converter
operating 1
Not operating
–40
–40
–40
60
90 2
100
°C
1
2
See Thermal Considerations
See table 4 and 5 P o derating
BCD20021-G Rev AC1, 13-May-2013
Page 13 of 21
www.power-one.com
